مشخصات فنی
یک عدد
Intel LGA 1151
Intel Socket 11519th / 8th Gen Intel® Core, Pentium Gold and Celeron Processors Supports Intel 14nm CPU Supports Intel Turbo Boost Technology 2.0 The Intel Turbo Boost Technology 2.0 support depends on the CPU types
Intel B360
DDR4
چهار عدد
64 گیگابایت
DDR4 2666/2400/2133 MHz Non-ECC Un-buffered مگاهرتز
دو کاناله
دو مسیره
Integrated Graphics Processor- Intel HD Graphics support Multi-VGA output support : HDMI/DVI-D ports - Supports HDMI with max. resolution 4096 x 2160 @ 24Hz - Supports DVI-D with max. resolution 1920 x 1200 @ 60Hz Multi-GPU Support - Supports AMD 2-Way CrossFireX Technology
چهار عدد
دو عدد
24 مسیر
۲ مسیر PCIe 3.0/2.0 x16 (x16/x4) x1 ۴ مسیر PCIe 3.0/2.0 x1 x2
دو عدد
PCI-E 3.0 x4، SATA 3.0
شش
Intel I219V
Intel I219V, Dual interconnect between the Integrated Media Access Controller (MAC) and Physical Layer (PHY) Anti-surge LANGuard ROG GameFirst Technology
دو عدد
چهار عدد
ROG SupremeFX8-Channel High Definition Audio CODEC S1220A
ROG SupremeFX8-Channel High Definition Audio CODEC S1220A - Dual OP Amplifiers - Impedance sense for front and rear headphone outputs - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality120dBSNR stereo playback outputand113dBSNR recording input - Supports up to 32-Bit/192kHz playback Audio Feature : - SupremeFX Shielding™ Technology - Optical S/PDIF out port(s) at back panel - Sonic Radar III - Sonic Studio III + Sonic Studio Link
یک عدد کومبو
یک عدد
5 عدد
۱ عدد PS/2 keyboard/mouse combo port ۱ عدد DVI-D ۱ عدد HDMI ۱ عدد LAN (RJ45) port ۲ عدد USB 3.1 Gen 2 (red)Type-A ۲ عدد USB 3.1 Gen 1 (blue) ۲ عدد USB 2.0 ۱ عدد Optical S/PDIF out ۵ عدد Audio jack
دو عدد
یک عدد
۰
۰
7 فاز
4 عدد
کانکتور برق اصلی 24 پبن ATX، کانکتور برق 8 پین ATX
۱ عدد Clear CMOS jumper
۱ عدد USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) ۱ عدد Aura RGB Strip Header ۲ عدد USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
۱ عدد 128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS ASUS EZ Flash 3, CrashFree BIOS 3, Secure Erase, User Profile, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, F4 AURA ON/OFF and F9 Search
WOL, PXE
ATX
PCIe x16_2 slot shares bandwidth with PCIe x1_3 and PCIe x1_4 slots. When PCIe x1_3 and PCIe x1_4 slots are occupied, PCIe x16_2 slot runs at x2 mode When both PCIe x1_1 and PCIe x1_2 slots are occupied, only the device installed in the PCIe x1_1 slot can be detected. Adjust BIOS settings to use PCIe x1_2 slot The M.2_1 socket shares bandwidth with SATA_2 port when using M.2 SATA mode device. Adjust BIOS settings to use SATA device The M.2_2 socket supports Intel Optane Technology. Intel Optane™ Technology only supported when using 8th Generation Intel Processors. Before using Intel Optane memory modules, ensure that you have updated your motherboard drivers and BIOS to the latest version from ASUS support website Intel Optane Memory is only available on M.2_2 slot Supports 3A power output, one at a time only
